SFP
SFP-100TX
125M SFP-100TX 光纖模組
Hot Pluggable, RJ-45, Active Copper 100M
| 產品料號 | 連接器 | 主機埠 | 網線連接速度 (RJ45接口) / 距離 | Rx_LOS 指示針腳 | 操作溫度 | 備註 | 規格書 |
|---|---|---|---|---|---|---|---|
| FSFP-AJ-T01-X1 | Copper RJ45 | 100BASE-FX | 100M @Cat.5 UTP cable, 100m | YES | 0~70°C | SFP-100TX | |
| FSFP-AJ-T01-X1i | Copper RJ45 | 100BASE-FX | 100M @Cat.5 UTP cable, 100m | YES | -40~85°C | SFP-100TX, I-Temp | |
| FSFP-AJ-T11-X1 | Copper RJ45 | 100BASE-FX | 10/100M @Cat.5 UTP cable, 100m | YES | 0~70°C | SFP-100TX | |
| FSFP-AJ-T11-X1i | Copper RJ45 | 100BASE-FX | 10/100M @Cat.5 UTP cable, 100m | YES | -40~85°C | SFP-100TX, I-Temp | |
- 10/100BASE-Tx Application
- Compatible with IEEE802.3u Standard
- Compliant with SFP MSA
- Hot Pluggable
- Auto-detect MDI/MDI-X on RJ-45 port
- Compatible with 10BASE-T and 100BASE-Tx auto-negotiation on RJ-45 port
- Support Rx_LOS(Loss Of Signal) function
- Single +3.3V power supply
- Link length up to 100m with four-pair Cat.5 UTP
- RoHS Compliant
