F520 OTN DWDM System
F520 1U 4-Slot Chassis
F520 1U 4-Slot Chassis 光纖傳輸轉換設備
| 詢價單 | 規格 | 特點 | 下載 |
|---|---|---|---|
| ParameterTechnical indicators Size (mm)1U 19” : 482.5 (W) x 350 (D) x 44.5 (H)Slot1-Slot for Management, 3-Slot for ServicePower SupplyDual Power Supply 100~240VAC, -48VDC optionalPower Consumption<120WFAN4*40mm FANEnviornment │ Operating Temperature-10 ~ 60 °CEnviornment │ Storage Temperature-40 ~ 85 °CEnviornment │ Relative Humidity5 ~ 95 RH% | 1U 19” Rack Compact size1 Slot for Management3 Slots for Service module cardsBulti-in Management unitModular design for Power and FAN moduleHot Pluggable, Easy Replacement1+1 Balanced and Redundancy Power supply,AC / DC optionalSupport SNMP-based Network managementSupport CLI, WEB, Telnet and NMSVisual Graphic information interfaceSupport Entire network topology, elements auto-discovery and generationSupport Voice alarm, e-mail alerts, SMS alerts, Real-time online remote monitoring |  | |
| ParameterTechnical indicators Size (mm)2U 19” : 482.5(W) x 350(D) x 89(H)Slot1-Slot for Management, 7-Slot for ServicePower SupplyDual Power Supply 100~240VAC, -48VDC optionalPower Consumption<200WFAN3*80mm FANEnviornment │ Operating Temperature-10 ~ 60 °CEnviornment │ Storage Temperature-40 ~ 85 °CEnviornment │ Relative Humidity5 ~ 95 RH% | 2U 19” Rack Compact size1 Slot for Management7 Slots for Service module cardsModular design for Power and FAN moduleHot Pluggable, Easy Replacement1+1 Balanced and Redundancy Power supply,AC / DC optionalSupport SNMP-based Network managementSupport CLI, WEB, Telnet and NMSVisual Graphic information interfaceSupport Entire network topology, elements auto-discovery and generationSupport Voice alarm, e-mail alerts, SMS alerts, Real-time online remote monitoring | | |
| ParameterTechnical indicators Size (mm)5U 19” : 482.5(W) x 350(D) x 222.5(H)Slot1-Slot for Management, 19-Slot for ServicePower SupplyDual Power Supply 100~240VAC, -48VDC optionalPower Consumption<500WFAN6*80mm FANEnviornment │ Operating Temperature-10 ~ 60 °CEnviornment │ Storage Temperature-40 ~ 85 °CEnviornment │ Relative Humidity5 ~ 95 RH% | 5U 19” Rack Compact size1 Slot for Management19 Slots for Service module cardsModular design for Power and FAN moduleHot Pluggable, Easy Replacement1+1 Balanced and Redundancy Power supply,AC / DC optionalSupport SNMP-based Network managementSupport CLI, WEB, Telnet and NMSVisual Graphic information interfaceSupport Entire network topology, elements auto-discovery and generationSupport Voice alarm, e-mail alerts, SMS alerts, Real-time online remote monitoring 📣 解鎖短距離傳輸：如何最大化光網路解決方案！🌟 FICER F520 OTN DWDM 傳輸平台（高密度波分複用光纖骨幹傳輸系統設備）專為解決您的光纖網路挑戰而設計，具有易於使用、安裝、部署和管理的特點。其主要功能是處理多個光信號。利用波長轉換、複用、解複用、光放大和光色散補償等技術，它可以在有限的光纖資源上傳輸多個高帶寬信號到遠距離目的地。這使得客戶能夠在不部署新電纜的情況下，利用現有的光纖資源實現超長距離傳輸，達到傳統光模組無法實現的帶寬擴展。主要特點包括高密度集成平台、高度靈活的配置能力和高容量（能夠在不同功能卡下執行各種任務）。適用於城域內或城域網路之間的帶寬擴展、長距離骨幹傳輸和海量數據容量傳輸等場景。此外，FICER F520 設備提供靈活性，能夠構建經濟高效的光傳輸網絡。非常適合電信運營商、企業、金融機構、公用事業單位、政府機構、廣播公司、教育網絡和內容服務提供商使用。更多 F520 OTN DWDM 傳輸平台資訊 | | |
| Advanced Optical Service Channel (OSC) protocolSecurityAlarm ManagementMultiple management modeGraphical User Interface (GUI) managementMultiple front panel ports for management accessExtensive management features | | ||
| Metro CWDM / DWDM distance extensionLong-Haul transmission systemWavelength ConversionSignal RepeatingMedia Conversion | 3R signal regeneration (Reshaping, Retiming, Reamplify)Support multiple services and Wide data rate : 1.25Gbps~11.3GbpsHot SwapReal-Time DDMSupport ALS (Automatic Laser Shutdown)Support LFP (Link Forward Pass though)Ultra-Low latencyLow power consumptionSupport all F520 Chassis | | |
| Metro CWDM / DWDM distance extensionLong-Haul transmission systemWavelength ConversionSignal RepeatingMedia Conversion | 1R signal regeneration (Reamplify)Support multiple services and Wide data rate : 1.25Gbps~28GbpsHot SwapReal-Time DDMSupport ALS (Automatic Laser Shutdown)Ultra-Low latencyLow power consumptionSupport all F520 Chassis | ||
| Metro DWDM distance extensionLong-Haul transmission systemSignal RepeatingMedia ConversionLambda Conversion | Client side: 1*100G QSFP28Line side: 1*100G CFPHot SwapSupport Line-side GFEC (G.709 RS-FEC), EFEC and SDFEC (depends on CFP-DCO module)Support port loopback testDispersion Tolerance up to 40000ps/nm (depends on CFP-DCO module)Support adjustable wavelength with CFP-DCO moduleSupport adjustable output power with CFP-DCO moduleSupport OSNR real-time monitoring with CFPDCO moduleSupport all F520 Chassis | | |
| Metro DWDM distance extensionLong-Haul transmission systemSignal RepeatingMedia ConversionLambda Conversion | Client side: 3*40/100G QSFP28Line side: 3*40/100G QSFP28Back-to-Back transparent transmissionHot SwapReal-Time DDMSupport ALS (Automatic Laser Shutdown)Support LFP (Link Forward Pass though)Low power consumptionSupport all F520 Chassis | | |
| Metro DWDM distance extensionLong-Haul transmission systemSignal RepeatingMedia ConversionLambda Conversion | Client side: 1*400G QSFP56-DDLine side: 1*400G CFP2Support Line-side GFEC (G.709 RS-FEC), EFEC and SDFEC (depends on CFP2-DCO module)Dispersion Tolerance up to 40000ps/nm (depends on CFP2-DCO module)Support adjustable wavelength with CFP2-DCO moduleSupport adjustable output power with CFP2-DCO moduleSupport OSNR real-time monitoring with CFP2-DCO moduleSupport port Loopback testHot SwapReal-Time DDMSupport ALS (Automatic Laser Shutdown)Support all F520 Chassis | ||
| Metro DWDM distance extensionLong Haul transmission systemSignal RepeatingMedia ConversionLambda Conversion | Client side: 1*40/100G QSFP28Line side: 4*10/25G QSFP28Back to Back transparent transmissionHot SwapReal Time DDMSupport ALS ( Automatic Laser Shutdown )Low power consumptionSupport all F520 Chassis | | |
| Metro DWDM distance extensionLong Haul transmission systemSignal RepeatingMedia ConversionLambda Conversion | Client side: 10*10G SFP+Line side: 1*100G QSFP28Support 10G and 100G EtherenetHot SwapReal-Time DDMSupport ALS (Automatic Laser Shutdown)Low power consumptionSupport all F520 Chassis | | |
| Metro DWDM distance extensionLong-Haul transmission systemSignal RepeatingMedia ConversionLambda Conversion | Client side: 2*100G QSFP28Line side: 1*100/200G CFP2Hot SwapSupport Line-side GFEC (G.709 RS-FEC), EFEC and SDFEC (depends on CFP-DCO module)Support port loopback testDispersion Tolerance up to 40000ps/nm (depends on CFP2-DCO module)Support adjustable wavelength with CFP2-DCO moduleSupport adjustable output power with CFP2-DCO moduleSupport OSNR real-time monitoring with CFP2-DCO moduleSupport all F520 Chassis | | |
| Metro DWDM distance extensionLong-Haul transmission systemSignal RepeatingMedia ConversionLambda Conversion | Client side: 4*100G QSFP28Line side: 1*100/200/400G CFP2Support Line-side GFEC (G.709 RS-FEC), EFEC and SDFEC (depends on CFP2-DCO module)Support Client-side 100GE RS(528,514) FECDispersion Tolerance up to 40000ps/nm (depends on CFP2-DCO module)Support adjustable wavelength with CFP2-DCO moduleSupport adjustable output power with CFP2-DCO moduleSupport OSNR real-time monitoring with CFP2-DCO moduleSupport port Loopback testHot SwapReal-Time DDMSupport ALS (Automatic Laser Shutdown)Support all F520 Chassis | | |
| Metro DWDM distance extensionLong-Haul transmission systemSignal RepeatingMedia ConversionLambda Conversion | Client side: 4*100G QSFP28Line side: 1*400G QSFP56-DDSupport Line-side Multi-Rate 100/200/300/400G (depends on QSFP56-DD DCO module)Support Line-side oFECSupport Client-side 100GE RS(528,514) FECDispersion Tolerance up to 20000ps/nm @400G (depends on QSFP56-DD DCO module)Support adjustable wavelength with QSFP56-DD DCO moduleSupport adjustable output power with QSFP56-DD DCO moduleSupport OSNR real-time monitoring with QSFP56-DD DCO modulSupport port Loopback testHot SwapReal-Time DDMSupport ALS (Automatic Laser Shutdown)Support all F520 Chassis | | |
| Metro DWDM distance extensionSingle wavelength distance extensionCATV network systemLong-Haul transmission system | Low noise figure : typical 5dBGain Flattening Filters ( GFF ) assure flat Gain ( <1dB variance ) over the entire amplified bandMultiple operating modes : AGC, APC, ACCHigh performance transient response control to ensure Power, Gain stable without affecting existing signalSupport customized saturated Output Power range 13 ~ 24dBmSupport customized Gain variety range 8 ~ 40dBSupport Red / Blue port for single-fiber DWDM transmission systemSupport Mid-Stage access for insertion of a DCM or OADM unit without it’s inherent loss.Optional OSC management channel for remote managementOwn monitoring port, real-time monitoring optical power and OSNRSupport SNMP, Web, Console managementSupport 4, 8, 20 slot chassis for different capacity requirement | |
