| 詢價單 | 規格 | 應用 | 特點 | 下載 |
| | | Part Number | Data Rate | Dimension | Adaptor | Material | Splice Tray | Box Body | Full Package | Datasheet |
|---|
| FFDB-RM- 24Sx-xxxxxx | 24port | 430mm x 300mm x 45mm (1U) | SC/FC/ST/LC | Aluminum | 150mm x 110mm (12 Cores) x 2pcs | 4.0kg | 4.5kg |  | | FFDB-R24AE1-xxxxxx | 24port | 430mm x 300mm x 45mm (1U) | SC/FC/ST/LC | Aluminum | 230mm x 130mm (24 Cores) x 1pc | 1.5kg | 2.0kg | | | FFDB-R48AE1-xxxx | 48port | 430mm x 300mm x 175mm (4U) | SC/FC/ST/LC | Aluminum | 230mm x 130mm (24 Cores) x 2pcs | 3.0kg | 4.2kg | | | FFDB-R96AE1-xxxx | 96port | 430mm x 300mm x 300mm (6.5U) | SC/FC/ST/LC | Aluminum | 230mm x 130mm (24 ports) x 4pcs | 4.6kg | 6.2kg | | | FFDB-RM-120Ax-xxxxxx | 120port | 430mm x 300mm x 310mm (7U) | SC/FC/ST/LC | Aluminum | 230mm x 130mm (24 Cores) x 5pcs | 5.0kg | 6.5kg | | | FFDB-R144AE1-xxxx | 144port | 430mm x 300mm x 360mm (8U) | SC/FC/ST/LC | Aluminum | 230mm x 130mm (24 ports) x 6pcs | 5.0kg | 6.8kg | |
| - LAN / WAN
- CATV Network
- FTTx Network
| - Easy Installation & Maintenance
- High reliability and stability
- SC / FC / ST / LC Adaptor or Option
- Anti-Rust paint coating
- Cost Effective
- Sliding Rail
| - |
| | | Part Number | Data Rate | Dimension | Adaptor | Material | Splice Tray | Box Body | Full Package | Datasheet |
|---|
| FFDB-WM-8Ax-xxxxxx | 8port | 150mm x 150mm x 47mm | SC/FC/ST/LC | Aluminum | Replaced with Splice Comb | 0.35kg | 0.45kg | | | FFDB-WM-12Cx-xxxxxx | 12port | 57mm x 105mm x 155mm | SC/FC/ST/LC | Aluminum | 100mm x 80mm (12 Cores) x 1pcs | 0.4kg | 0.5kg | | | FFDB-WM-24Ax-xxxxxx | 24port | 250mm x 250mm x 60mm | SC/FC/ST/LC | Aluminum | 160mm x 80mm (12 Cores) x 2pcs | 1.0kg | 1.2kg | | | FFDB-WM-48Ax-xxxxxx | 48port | 300mm x 300mm x 100mm | SC/FC/ST/LC | Aluminum | 160mm x 100mm (12 Cores) x 4pcs | 1.3kg | 1.6kg | | | FFDB-WM-96Ax-xxxxxx | 96port | 430mm x 350mm x 150mm | SC/FC/ST/LC | Aluminum | 230mm x 130mm (24 Cores) x 4pcs | 3.0kg | 4.0kg | |
| - LAN / WAN
- CATV Network
- FTTx Network
- Floor Fiber Distribution
| - Easy Installation & Maintenance
- High reliability and stability
- SC / FC / ST / LC Adaptor or Option
- Anti-Rust paint coating
- Compact Dimension
- Cost Effective
| - |
| | | Part Number | Data Rate | Dimension | Adaptor | Material / Color | Splice Tray | Box Body | Full Package | |
|---|
| FFDB-WM-48PG-xxxxxx-LT1 | 48port | 380mm x 320mm x 115mm | SC/FC/ST | PC+ABS / Gray | 24 Cores x 2pcs | 2.0kg | 2.8kg |
| - FTTx Network
- CATV Network
- Telecommunication Network
- Local Area Network
| - Total enclosed structure
- PC+ABS outer case
- IP65 protection rating
- SC / FC / ST / LC Adaptor or Option
- Easy Installation and Maintenance
- High Reliability and Stability
- Wall-Mount accessories included
| |
