10G SFP+
10G SFP+ Duplex
10G SFP+ 光纖模組
Hot Pluggable, Duplex LC, 850nm / 1310nm / 1550nm, Multi-Mode / Single Mode, 300M~100KM
| 產品料號 | 資料傳輸率 | 波長 | 連接器 | 傳輸距離 | 操作溫度 | 備註 | 規格書 |
|---|---|---|---|---|---|---|---|
| FSPP-H7-M85-X3D | 10G | 850nm | Duplex LC | OM3 300m | 0~70°C | SFP+ 10G-SR, C-Temp | |
| FSPP-H7-M85-X3Di | 10G | 850nm | Duplex LC | OM3 300m | -40~85°C | SFP+ 10G-SR, I-Temp | |
| FSPP-H7-M85-X3DM | 10G | 850nm | Duplex LC | OM3 300m | 0~70°C | SFP+ 10G-SR, Multi-Rate, C-Temp | |
| FSPP-H7-M85-X3DMi | 10G | 850nm | Duplex LC | OM3 300m | -40~85°C | SFP+ 10G-SR, Multi-Rate, I-Temp | |
| FSPP-H7-M13-X2D | 10G | 1310nm | Duplex LC | OM3 220m | 0~70°C | SFP+ 10G-LRM, C-Temp | |
| FSPP-H7-M13-X2Di | 10G | 1310nm | Duplex LC | OM3 220m | -40~85°C | SFP+ 10G-LRM, I-Temp | |
| FSPP-H7-M13-X2D-SX3 | 10G | 1310nm | Duplex LC | OM3 220m SM 300m | 0~70°C | SFP+ 10G-LRM MM 220m, SM 300m | |
| FSPP-H7-M13-X2Di-SX3 | 10G | 1310nm | Duplex LC | OM3 220m SM 300m | -40~85°C | SFP+ 10G-LRM MM 220m, SM 300m, I-Temp | |
| FSPP-H7-S13-02D | 10G | 1310nm | Duplex LC | SM 2km | 0~70°C | SFP+ 10G-LRL, C-Temp | |
| FSPP-H7-S13-02Di | 10G | 1310nm | Duplex LC | SM 2km | -40~85°C | SFP+ 10G-LRL, I-Temp | |
| FSPP-H7-S13-02DM | 10G | 1310nm | Duplex LC | SM 2km | 0~70°C | SFP+ 10G-LRL, Multi-Rate, C-Temp | |
| FSPP-H7-S13-02DMi | 10G | 1310nm | Duplex LC | SM 2km | -40~85°C | SFP+ 10G-LRL, Multi-Rate, I-Temp | |
| FSPP-H7-S13-10D | 10G | 1310nm | Duplex LC | SM 10km | 0~70°C | SFP+ 10G-LR, C-Temp | |
| FSPP-H7-S13-10Di | 10G | 1310nm | Duplex LC | SM 10km | -40~85°C | SFP+ 10G-LR, I-Temp | |
| FSPP-H7-S13-10D-LP1 | 10G | 1310nm | Duplex LC | SM 10km | 0~70°C | SFP+ 10G-LR, Low Power Consumption | |
| FSPP-H7-S13-10Di-LP1 | 10G | 1310nm | Duplex LC | SM 10km | -40~85°C | SFP+ 10G-LR, Low Power Consumption, I-Temp | |
| FSPP-H7-S13-10DM | 10G | 1310nm | Duplex LC | SM 10km | 0~70°C | SFP+ 10G-LR, Multi-Rate | |
| FSPP-H7-S13-10DMi | 10G | 1310nm | Duplex LC | SM 10km | -40~85°C | SFP+ 10G-LR, Multi-Rate, I-Temp | |
| FSPP-H7-S13-20D | 10G | 1310nm | Duplex LC | SM 20km | 0~70°C | SFP+ 10G-LR20 | |
| FSPP-H7-S13-20Di | 10G | 1310nm | Duplex LC | SM 20km | -40~85°C | SFP+ 10G-LR20, I-Temp | |
| FSPP-H7-S13-20DM | 10G | 1310nm | Duplex LC | SM 20km | 0~70°C | SFP+ 10G-LR20, Multi-Rate | |
| FSPP-H7-S13-20DMi | 10G | 1310nm | Duplex LC | SM 20km | -40~85°C | SFP+ 10G-LR20, Multi-Rate, I-Temp | |
| FSPP-H7-S13-40D | 10G | 1310nm | Duplex LC | SM 40km | 0~70°C | SFP+ 10G-ER-1310 | |
| FSPP-H7-S13-40Di | 10G | 1310nm | Duplex LC | SM 40km | -40~85°C | SFP+ 10G-ER-1310, I-Temp | |
| FSPP-H7-S13-40DM | 10G | 1310nm | Duplex LC | SM 40km | 0~70°C | SFP+ 10G-ER-1310, Multi-Rate | |
| FSPP-H7-S13-40DMi | 10G | 1310nm | Duplex LC | SM 40km | -40~85°C | SFP+ 10G-ER-1310, Multi-Rate, I-Temp | |
| FSPP-H7-S13-60D | 10G | 1310nm | Duplex LC | SM 60km | 0~70°C | SFP+10G-ER+1310 60km, C-Temp | |
| FSPP-H7-S13-60Di | 10G | 1310nm | Duplex LC | SM 60km | -40~85°C | SFP+10G-ER+1310 60km, I-Temp | |
| FSPP-H7-S13-70D | 10G | 1310nm | Duplex LC | SM 70km | 0~70°C | SFP+10G-ZR-1310 70km(28dB), C-Temp | |
| FSPP-H7-S13-70Di | 10G | 1310nm | Duplex LC | SM 70km | -40~85°C | SFP+10G-ZR-1310 70km(28dB), I-Temp | |
| FSPP-H7-S15-40D | 10G | 1550nm | Duplex LC | SM 40km | 0~70°C | SFP+ 10G-ER | |
| FSPP-H7-S15-40Di | 10G | 1550nm | Duplex LC | SM 40km | -40~85°C | SFP+ 10G-ER, I-Temp | |
| FSPP-H7-S15-40DM | 10G | 1550nm | Duplex LC | SM 40km | 0~70°C | SFP+ 10G-ER, Multi-Rate | |
| FSPP-H7-S15-40DMi | 10G | 1550nm | Duplex LC | SM 40km | -40~85°C | SFP+ 10G-ER, Multi-Rate, I-Temp | |
| FSPP-H7-S15-80D | 10G | 1550nm | Duplex LC | SM 80km | 0~70°C | SFP+ 10G-ZR | |
| FSPP-H7-S15-80Di | 10G | 1550nm | Duplex LC | SM 80km | -40~85°C | SFP+ 10G-ZR, I-Temp | |
| FSPP-H7-S15-80DM | 10G | 1550nm | Duplex LC | SM 80km | 0~70°C | SFP+ 10G-ZR, Multi-Rate | |
| FSPP-H7-S15-80DMi | 10G | 1550nm | Duplex LC | SM 80km | -40~85°C | SFP+ 10G-ZR, Multi-Rate, I-Temp | |
| FSPP-H7-S15-A0D | 10G | 1550nm | Duplex LC | SM 100km | 0~70°C | SFP+ 10G-ZR100 | |
| FSPP-H7-S15-A0Di | 10G | 1550nm | Duplex LC | SM 100km | -40~85°C | SFP+ 10G-ZR100, I-Temp | |
| FSPP-H7-S13-10DQ | 10G | 1310nm | Duplex LC | SM 10km | 0~70°C | SFP+ 10G-LR-CDR | |
| FSPP-H7-S13-10DQi | 10G | 1310nm | Duplex LC | SM 10km | -40~85°C | SFP+ 10G-LR-CDR, I-Temp | |
| FSPP-H7-S15-40DQ | 10G | 1550nm | Duplex LC | SM 40km | 0~70°C | SFP+ 10G-ER-CDR | |
| FSPP-H7-S15-40DQi | 10G | 1550nm | Duplex LC | SM 40km | -40~85°C | SFP+ 10G-ER-CDR, I-Temp | |
| FSPP-H7-S15-80DQ | 10G | 1550nm | Duplex LC | SM 80km | 0~70°C | SFP+ 10G-ZR-CDR | |
| FSPP-H7-S15-80DQi | 10G | 1550nm | Duplex LC | SM 80km | -40~85°C | SFP+ 10G-ZR-CDR, I-Temp | |
- 10GBASE LR/LW Ethernet @10.3125G
- Fiber Channel 800 SM LC L 8GFC @8.5G, 1200-SM-LL-L 10GFC @10.51875G
- SONET OC 192 & SDH STM 64 @9.953G
- CPRI Option #7 @9.83G, #8 @10.1376G
- OTN OTU2 @10.7G, OTU2e @11.09G, OTU2f @11.32G
- Compliant with IEEE802.3ae 10GBase Ethernet
- Compliant with CPRI Option 7, 8
- Compliant with SFF 8431 , SFF 8432 SFP+ MSA
- Support 8.5Gb/s to 11.32Gb/s Multi Rate
- 850nm/1310nm/1550nm laser transmitter
- 2 wire interface for management and diagnostic monitor compliant with SFF 8472
- Single +3.3V power supply
- Link distance 300m over MM fiber (SFP+ 10G-SR)
- Link distance 2km~100km over SM fiber
