F520 DWDM 1U Rack-Mount EDFA
F520 DWDM 1U Rack-Mount EDFA ( Erbium-Doped Optical Fiber Amplifier )
- Metro DWDM distance extension
- C-Band DWDM signals amplifying
- CATV network system
- Long-Haul transmission system
- Fixed 1U Rack package, LC optical port
- Low Noise Figure : typical 5dB, MAX 5.5dB
- Multiple operating modes : AGC, APC, ACC
- High performance transient response control to ensure Power, Gain stable without affecting existing signal
- Support customized saturated Output Power up to +22dBm
- Support customized Gain variety range 8 ~ 35dB
- Optional OSC management channel for remote management
- Support Red / Blue port for the single-fiber DWDM transmission system
- Support Mid-Stage access for the insertion of a DCM or OADM unit without its inherent loss
- MON port for on-line monitoring optical power and OSNR
- Support LCD screen with Panel buttons control
- Support SNMP, Web management
- 1+1 Pluggable Redundancy Power supply, AC / DC optional
